Ultrasonic separators utilize an additional source of vibration to increase capacity and reduce clogging, specifically designed for ultra-fine powder separation. High frequency ultrasonic vibration is generated and applied directly onto the screen, breaking the static bonds between particles, therefore increases production speed and efficiency.
Specification of Ultrasonic Generator
Generator Specification:
Power: 220V, 50/60Hz, Single-Phase
Power Consumption: 1A (Max.)
Output Frequency: 36KHz
Operating Mode: Continuous Mode / Pulse Mode
Box Dimension (WxHxD): 165 x 230 x 400mm
Transducer:
Casing: Stainless Steel SS304
Position: Above Screen (Standard)
Features
● Prevents clogging - high frequency vibration prevents particles becoming stagnant on the screen, and breaks static bonding between particles.
● Does not dust - low amplitude vibration, does not create dust clouds.
● Increase productivity and efficiency - fine particles pass through quickly and do not build up on the screen, eliminate the need to manually clear the screen.
● Suitable for fine powder separation - can easily separate powder as fine as 15μm, otherwise inseparable without ultrasonic vibration.
● Stainless steel transducer - transducer casing is stainless steel SS304.
